Next 07 ET Transparent Ether-TPU Hose with TPU-Coated AISI 302 INOX Steel Helix

Product Code: N7ET

Ether-Based TPU Ducting | Food Safe, Antistatic - Next 07 ET

Description

Next 07 ET transparent ether-based TPU (Thermoplastic Polyurethane) ducting with constant 0.7mm wall thickness. This hose is not just another piece of tubing; it's a robust, versatile conduit designed to meet the exacting standards of the food processing and pharmaceutical sectors. Reinforced with an AISI 302 INOX steel spiral coated in TPU, it ensures unparalleled adhesion, enhancing the functionality of the hose. The inner surface is completely smooth, promoting optimal flow characteristics essential for the gentle handling of sensitive or abrasive media.

Key Features:

Tailored for the food processing and pharmaceutical industries where precision and material integrity are critical.
Well-suited for the light suction of abrasive media, ensuring minimal wear and tear on both the hose and the transported materials.
Properties: Transparent ether-based TPU for visibility and quality control.
Anti-static and Conductivity: Permanently antistatic (R<10⁹ Ohm/m) to prevent static buildup with a smooth internal surface for efficient flow. The hose's conductive capability through spiral grounding (R<10² Ohm/m) adds an extra layer of safety in static-sensitive operations.
Resistance: Resistant to UV, microbes, hydrolysis, mineral oils, chemicals, and weathering.
Diameter Range: Available in diameters from 50.8 to 203.2 mm to accommodate various system requirements.

Next 07 ET is your go-to solution for applications requiring a hose with superior chemical resistance, flexibility, and the ability to handle abrasive substances gently. Its compliance with EU Regulation 10/2011 and FDA CFR 21-Item 177.2600 confirms its suitability for direct food contact, ensuring safety and compliance in your operations. While its neutrality in taste and odor keeps the integrity of the conveyed medium intact, making it perfect for food-grade applications where purity is paramount. Choose Next 07 ET for a reliable, high-performance hose that meets the rigorous demands of modern food and pharmaceutical processing. Bore Finish: Smooth

Food Quality

FDA regulations (Title 21 CFR 177.2600 Part E for aqueous foods).
EU Regulation 10/2011 Food Simulant A: Hydrophilic Foods.
EU Regulation 10/2011 Food Simulant B: Foods with pH <4.5.
EU Regulation 10/2011 Food Simulant C: Alcohol up to 20%.
EU Regulation 10/2011 Food Simulant D1: Alcohol content >20% and oil-in-water emulsions.
EU Regulation 10/2011 Food Simulant D2: Foods with free fats at the surface.
EU Regulation 10/2011 Food Simulant E: Testing specific migration into dry foods.

Suitable Media

Abrasive media
Food
Pharmaceuticals
Granulates
Food powders
Animal feed
Granules
Grains
Sugar
Salt
Dry fruit
Fatty food
Abrasive powders
Food liquids
Drinks
Dairy products
Milk
Dry food
Powders
Beverages
Fruit juices
Wine
Liquors
By-products
Water
Vinegar
Spirits
Chemicals

Applications

Food industry
Pharmaceutical industry
Cosmetics
Street cleaning
Leaf collection
Paddock cleaning
Dust extraction
Plastics industry
Glass making
Ceramics
Woodworking
Sawmills
Granule drying
Printing and paper industries
Liquid food industry
Wine making
Brewery
Chemical industry

Temperature

-40°C to 90°C

Electrical Resistance

Conductive to 10² Ω/m by grounding the copper braid wire.

Construction

Wall: Ether-TPU
Helix: TPU-Coated AISI 302 INOX Stainless steel

Certification

EU 10/2011
FDA 21 CFR 177.2600
RoHS
REACH

Available Colours

Clear

Part	Inner Diameter	Wall Thickness	Vacuum Rating	Bend Radius	Weight	Length	Volume	Availability

N7ET052	50.8	0.7	2	50	360	30	0.182	Good
N7ET060	60	0.7	1.7	70	420	30	0.211	Production
N7ET063	63.5	0.7	1.7	70	430	30	0.300	Good
N7ET065	65	0.7	1.7	75	440	30	0.307	Production
N7ET070	70	0.7	1.7	85	470	30	0.328	Production
N7ET076	76.2	0.7	1.7	90	475	30	0.355	Good
N7ET080	80	0.7	1.6	95	495	30	0.372	Good
N7ET090	90	0.7	1.6	105	555	20	0.276	Production
N7ET100	100	0.7	1.3	135	690	20	0.308	Production
N7ET102	102	0.7	1.3	135	705	20	0.313	Good
N7ET110	110	0.7	1.2	145	760	20	0.505	Production
N7ET120	120	0.7	1	160	785	20	0.548	Good
N7ET127	127	0.7	1	210	830	20	0.578	Production
N7ET140	140	0.7	0.8	185	915	20	0.634	Production
N7ET152	152	0.7	0.8	230	1100	20	0.817	Production
N7ET160	160	0.7	0.7	250	1160	20	0.856	Production
N7ET180	180	0.7	0.5	270	1305	20	0.958	Production
N7ET203	203	0.7	0.4	300	1625	15	1.08	Production

Please be advised; specifications assume standard room temperature unless otherwise specified. All data presented here is intended as a guide only; we are not responsible for errors or discrepancies in the specifications. Please click here for full terms and conditions. Please contact our sales office on 01636816612 or email us at sales@megaflex.co.uk for further details!
